| Order Code | Sensor & Size(mm) | Pixel(μm) | G Sensitivity Dark Signal | FPS/Resolution | Binning | Exposure |
| RT20SU-1M | 5.1M/AR0521(C) 1/2.5"(5.70x4.28) | 2.2x2.2 | 18.8ke-/lus 73dB 40dB | 30@2592x1944 30@1280x960 30@640x480 | 1x1 1x1 1x1 | 0.1~1000ms |
Other Hardware Configuration
| Spectral Range | 380-650nm (with IR-filter) |
| White balance | Auto/ROI/Manual White Balance(New Model) Auto(Products before 2020) |
| Color Rendering Technique | NA |
| Capture/Control SDK | Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C , C#/VB.NET, Python, Java, DirectShow, Twain, etc); |
| Recording System | Still Picture and Movie |
| Cooling System* | Natural |
Operating Environment
| Operating Temperature | -10℃~ 50℃ |
| Storage Temperature | -20℃~ 60℃ |
| Operating Humidity | 30~80%RH |
| Storage Humidity | 10~60%RH |
| Power Supply | DC 5V over PC USB Port |
Software Environment
| Operating System | Support Microsoft Windows XP / Vista / 7 /8 /10 (32 & 64 bit) OS X (Mac OS X), Linux |
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher Memory: 2GB or More USB port: USB2.0 High-speed Port Display: 17" or Larger CD-ROM |
